    2000KG/H Fruit Juice Making Machine With SUS304 Main Body

    Ask Lasest Price
    Brand Name : YGT
    Model Number : YGT-PW-2000
    Certification : CE
    Price : Negotiate
    Payment Terms : T/T, L/C
    Delivery Time : 20-40days
    • Product Details
    • Company Profile

    2000KG/H Fruit Juice Making Machine With SUS304 Main Body

    2000KG/Hr Fruit Juice Machine Made In China Processing Line


    Product Description


    2000KG/Hr Fruit Juice Machine Made In China Processing Line

    The fruit pulp and juice process is mainly composed of washer, Sort conveyor, Elevator, Crusher and Preheater / De-stoner , Pulping & Refiner, Buffer tank & pump, Evaporation, Holding tank, Sterilizer,Aseptic filler and other processes. The fruit pulp and juice process is mainly used in tomatoes, mangoes, guava and other products



    Specification

    Raw materialmango, tomato, guava
    Final productmango puree/jam, tomato paste, guava concentrate
    Capacity2-25t/h
    Juice yielding rate45-55%(mango), 90-95%(tomato)
    Soluble solid content (fresh juice)14-16brix (mango ), 4-4.5brix(tomato ), >9brix(guava)
    Soluble solid content (Final pulp)14/28brix (mango ), 28-30/36-38brix(tomato ), >20brix (guava )
    Consistency(Bostwick at 20℃)6-12/3.5-10(mango), 4-8(tomato),3.5-8(guava)
    Final product packageAseptic bag220/1400L//BIB 25L// Can tin 400g/800g

    Process Flow

    (1) Washer——first pass the original fruit through the washing machine for cleaning.
    (2) Sort conveyor——the cleaned raw fruit is selected by the elevator, and the bad raw fruit is picked out and removed
    (3) Juicing and beating —— the fruit is peeled and cored to squeeze the juice. There are many types of juicers, which can be selected according to the types of fruits and vegetables. Fruits need to be crushed or pre-cooked before juicing, which can increase the juice extraction rate
    (4) Concentration —— Juice that has been squeezed and pulped is transported to the concentration tank and evaporator for concentration through a transfer pump. The concentration tank and evaporator should also be selected according to the output and product environment requirements.
    (5) Holding Tank —— Transport the concentrated jam juice to the storage tank through a transfer pump for the next process

    (6) Sterilizer——the jam juice in the storage tank is delivered to the sterilization machine or sterilization pipeline through the transfer pump for sterilization.

    (7) Aseptic filler ——Finally, the product is filled through the filling machine. The choice of the filling machine depends on the form of the filled container, such as the filling of aseptic bags, glass bottles and other containers.


    Company Profile

    2000KG/Hr Fruit Juice Machine Made In China Processing Line.

    Our company mainly work for aseptic filler, sterilizer, juice extractor etc fruit processing equipment, all our engineer team work in this process industry with 12 years experience, except single key machine, we could also provide turnkey project solution. We have cooperated with many well-known dairy and beverage processing factories, such as China's Guangming Dairy, Mengniu, Yili, etc.
    Our Service
    Service for 2000KG/Hr Fruit Juice Machine Made In China Processing Line.
    (1) Reply in 24 hours
    (2) Providing professional solutions
    (3) Every product will be tested before the delivery
    (4) Delivery on time and excellent after-sale service
    (5) High quality, reliable price
    Certification
    FAQ
    1. Who are we?
    We are based in Shanghai, China, start from 2006,sell to Mid East(15.00%),Eastern Asia(15.00%),Western Europe(12.00%),North America(10.00%),Africa(10.00%),Southeast Asia(10.00%),Northern Europe(6.00%),South America(5.00%),Eastern Europe(5.00%),Oceania(5.00%),South Asia(4.00%),Southern Europe(3.00%). There are total about 51-100 people in our office.

    2. How can we guarantee quality?
    Always a pre-production sample before mass production;
    Always final Inspection before shipment;

    3. What can you buy from us?
    sterilization machine,pasteurizer machine,heat exchange,CIP system,filling machine

    4. Why should you buy from us not from other suppliers?
    1. update the technology every year, and with many sole patent 2. choose top international brand for as material and part, to guarantee equipment steady 3. long term available for spare parts like sealing and gasket

    5. What services can we provide?
    Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA;
    Accepted Payment Currency:USD,CNY;
    Accepted Payment Type: T/T,L/C,MoneyGram,PayPal,Western Union;
    Language Spoken:English,Chinese,Japanese,German,French,Korean,Italian
